Pneumatic Plastic Ultrasonic Welding Machine For Polyester Ribbon Welding 15KHz
GW series ultrasonic welding machine is equipped with the sixth
generation iQS operating system, built-in support code scanning
gun, data traceability. The welding machine is framed by metal mold
casting, with the high-performance rigid square column, and the
frame structure can be adjusted by motor lifting, which is easy to
operate. The generator used by the GW welding machine is a digital
intelligent touch screen generator, equipped with real-time
frequency automatic tracking display, overload protection, and
fault alarm functions, the internal program is composed of a full
series of modular, with a variety of welding modes. The welding
machine due to its strong equipment with accurate and mature drive
components can meet the customer's conventional welding
requirements, welding strength can be close to the strength of raw
materials, with a unique welding effect, very powerful function.
Technical parameters:
| Model | GW-SS1530 | GW-SS2020 |
| Frequency | 15KHz | 20KHz |
| Power | 3000W | 2000W |
| Triggering Method | Time, position |
| Welding Method | Time/Energy/Absolute Position |
| Max working Stroke(mm) | 80mm±1mm |
| Max Welding Time | 6s |
| Voltage(V) | AC220V±5% 50/60Hz |
| Accessory expansion (optional) | Noise insulation shield / Automatic film winding device/Auxiliary
fixture *2/Safety curtain for protection |
| Dimension(L*W*H)mm | 350mm*622mm*1140mm |
| Weight(kg) | 96.5kg |
Features:
* The 6th generation iQS operation system
* Built-in scanning gun for data tracing
* Mounted lifting motor for structural adjustment
* Modular structures with multiple welding modes designed for the
whole series of welders
* Metal die-casted stand column in square structure with
high-performance rigidity
Our Advantages:
1. 25 years ultrasonic plastic welding machine manufacture
experience;
2. We have been certified by ISO9001 quality management system,
ISO1400 environmental management system, CE certification;
3. Technical staffs have more than 25-year experience in ultrasonic
devices research, development, and manufacture;
4. First-class sales team, providing customers with valuable
products and services;
5. High-quality promise, One-year Warranty for machines and 3
months warranty for tooling;
6. Professional after-sales service team, lifelong technical
support.
Quality Control
1. After the customer confirms the demand, we will strictly control
each link of the product production;
2. At the same time, as the company sales, will follow up every
link of the order for our customers;
3. We have a QC team, All of our products will have 100% QC
inspection before shipment.
4. “Sustainable and permanent operation" is our vision and goal,
and we will provide continuous services for new and old customers
for the long run.
Detailed Photos:
ultrasonic plastic welder, ultrasonic plastic welding machine
manufacturer
